Siemens Standard application AHU CE1P3977en_02
Building Technologies Alarming 01.02.2010
Alarm Text Notification
class / group
Alarm no.
room unit
Settings 1 Settings 2
Hrec pump fdbk 2/B 43 StrtUpDly 10 s Time delay 5s
Hrec supply air tmp 2/B 29 Time delay 0s
Hrec water tmp 1/A 83 Low Limit -2.0 °C Time delay 0s
Htg 2 frost monitor 1/A 86 Time delay 0s
Htg frost monitor 1/A 85 Time delay 0s
Htg pump alarm 2/B 34 Time delay 0s
Htg pump fdbk 2/B 34 StrtUpDly 10 s Time delay 0s
Hum pump alarm 2/B 37 Time delay 0s
Hum pump fdbk 2/B 37 StrtUpDly 30 s Time delay 5s
Humidifier fdbk 2/B 38 StrtUpDly 10 s Time delay 5s
IO extension module 0/A Time delay 0 s
Manual mode 2/B 22 Time delay 1800 s
Modbus comm 2/B 23 Time delay 10 s
Not config IO 0/not Exist Time delay 0 s
Outs air dampr fdbk 1/A 65 StrtUpDly 180 s Time delay 5s
Outs air hum rel 2/B 47 High Limit 100 % rel Time delay 0s
Outside air temp 2/B 25 Time delay 0s
Processbus comm 2/B 23 Time delay 10 s
Room hum deviation 2/B 48
Max deviation = 10.0 %rel
Min Limit = 10.0 %rel
StrtUpDly 60 s
Time delay 3600 s
Room humidity rel 2/B 48 High Limit 100 % rel Time delay 0s
Room temperature 2/B 26 Time delay 0s
Room temperature 2 2/B 27 Time delay 0s
Room tmp deviation 2/B 33
Max deviation = 10.0 °C
Min Limit = 10.0°C
StrtUpDly 600 s
Time delay 3600 s
Room unit temp 2/B 24 Time delay 17m
Room unit temp 2 2/B 24 Time delay 17m
Sply air hum rel 2/B 46 High Limit 100% rel Time delay 0s
Sply fan deviation 0/A 69 StrtUpDly 180 s Time delay 60 s
Sply hum deviation 2/B 46
Max deviation = 5.0 %rel
Min Limit = 10.0 %rel
StrtUpDly 60 s
Time delay 3600s
Sply tmp deviation 2/B 32
Max deviation = 10.0 °C
Min Limit = 10.0°C
StrtUpDly 60 s
Time delay 3600s
Supply air flow 0/A 69 High Limit 40000 l/s Time delay 10s
Supply air pressure 0/A 69 High Limit 5000 Pa Time delay 10s
Supply air temp 1/A 60 Time delay 0s
Supply air tmp 2 2/B 30 Time delay 0s
Supply fan alarm 1/A 66 Time delay 0s
Supply fan fdbk 1/A 66 StrtUpDly 60 s Time delay 5s
Supply filter alarm 2/B 39 Time delay 0s
Supply tmp fire alm 1/A 81 Limit 70 °C Time delay 2s
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 229
