Appendix
166
General specifications
Handset
DECT
Maximum sound pressure level
according to TBR10, Annex D
less than 118 dB (A)
Weight incl. battery approx. 100 g
Dimensions (W x H X D) approx. 48 x 127 x 19 mm
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency range 1880-1,900 MHz
Duplex method Time multiplex, 10 ms frame length
Pulse repetition rate 100 Hz
Pulse transmission length 370 µs
Channel grid 1,728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW, average power per channel
250 mW pulse power
Range Up to 300 m outdoors, up to 50 m
indoors
Environmental conditions in
operation
+5 °C to +45 °C, 20 % to 75 %
relative humidity
