Siemens HiPath 3000 User Manual

Controls, parts of the device
7
Controls, parts of the device
How to use the keys:  page 24
1 Alarm and emergency call
key (red)
12 Jack for pull cord or dummy
connector
2 LED for indicating mode
activation and alarm status
13 Hash key
3 Example of a 2.5 mm jack
for headset (not for
OpenStage M3 Ex/
OpenStage M3 Ex Plus)
14 Number keys
4 Earpiece 15 On-hook and on/off key
5 Display 16 Message key
6 Display keys 17 Volume key (+/-)
7Control key 18Battery cover
8 Speakerphone key 19 Mini USB connection (under battery
cover)
9 Talk key 20 Screw for battery cover
10 Star key 21 Tone ringing/speakerphone
loudspeaker
11 Microphone 22 Notch for attachment clip (both sides)
5
6
7
8
16
9
15
10
12
14
18
21
2
4
11
17
13
20
1
3
22
19
