The parameters are sub-divided into groups according to their functionality. This
increases the transparency and allows a parameter to be quickly searched for.
Furthermore, parameter P0004 can be used to control the ability to be visualized for
the BOP / AOP.
Main parameter area:
ALWAYS 0 all parameters
INVERTER 2 drive inverter parameters 0200 .... 0299
MOTOR 3 motor parameters 0300 .... 0399 and
0600 .... 0699
ENCODER 4 speed encoder 0400 .... 0499
TECH_APL 5 technical applications / units 0500 .... 0599
COMMANDS 7 control commands, digital I/O 0700 .... 0749 and
0800 .... 0899
TERMINAL 8 Analog inputs/outputs 0750 .... 0799
SETPOINT 10 Setpoint channel and ramp-function gen. 1000 .... 1199
FUNC 12 Drive inverter functions 1200 .... 1299
CONTROL 13 Motor open-loop/closed-loop control 1300 .... 1799
COMM 20 Communications 2000 .... 2099
ALARMS 21 Faults, warnings, monitoring functions" 2100 .... 2199
Grouping
TECH 22 Technological controller (PID controller) 2200 .... 2399
Description for Binector Input (BI), Binector Output (BO), Connector Input (CI),
Connector Output (CO) and Connector Output / Binector Output (CO/BO), refer to
Section 3.1.2.3
BI Binector Input
BO Binector Output
CI Connector Input
CO Connector Output
BICO
CO/BO Connector Output / Binector Output
Description for the command data set (CDS) and drive data set (DDS) refer to Section
3.1.3
CDS Command data set
Data sets
DDS Drive data set
"P" parameters can only be changed depending on the drive state. The parameter
value is not accepted if the instantaneous state is not listed in the parameter attribute
"Change state". For instance, the commissioning (start-up) parameter P0010 with the
attribute "CT" can only be changed in quick start-up "C" or ready "T" but not in run
"U".
C Quick commissioning (start-up)
U Operation (run)
Change state
T Ready
This parameter attribute identifies as to whether the parameter is included in the quick
commissioning (start-up) (P0010 = 1).
No The parameter is not included in the quick commissioning (start-up)
QC.
Yes The parameter is included in the quick commissioning (start-up)
This attribute is only of importance in conjunction with a BOP. The "Immediate"
attribute indicates that this value is already accepted when scrolling (when changing
the value with
or ). Especially parameters which are used for optimization
functions have this property (e.g. constant voltage boost P1310 or filter time
constants). On the other hand, for parameters with the attribute "After actuation", the
value is only accepted after first actuating the key
. These include, for example,
parameters where the parameter value can have different settings/meanings (e.g.
selecting the frequency setpoint source P1000).
Immediately
The value becomes valid by either scrolling with
or
Active
After
actuation
The value is only accepted by pressing
