Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-117
Edition 12.2003
Editing (F1):
1. The path from the PG to the SS5 communications module SS5 is
saved in a path file. Select F1 "Edit" after a path and a path file have
been specified.
2. "PG/CP-L2" should now be selected as start station in the mask which
is now displayed. If this is not possible, then the CP5412 driver is
missing or the driver has not been started.
3. Select "CP-L2" as the only additional station and enter the station
address of the SS5 communications module to be addressed. This
must correspond with the SIMADYN D configuring (function block
@CSL2F).
4. A path must be edited once for each SS5 communications module.
Several paths can be saved in the same path file.
Active (F4):
This utility is used to test the connection to the SS5 communications
module.
The PG-L2 module CP5412 is initialized under this menu item and the
connection via PROFIBUS to the SS5 communications module created
via a "Path".
1. The currently entered path is activated by selecting F4 "Active". The
following steps should now be executed in the mask which is
displayed.
2. Select F3 "Next K."; the following is displayed: "Direct PC connection
established". Thus, the connection between COMSS5 and CP5412
has been established.
3. Depress F3 "Next K." again; the connection to the SS5
communications module is now established.
NOTE
If this does not function, then the baud rate and station address of
CP5412 (configuration file) and SS52 (central coupling block @CSL2F)
should be checked.
4. Return to the main menu with 2x F8
