Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-253
Edition 12.2003
The second line contains the message text, and is only output if there is a
message text. Otherwise this is completely eliminated.
Character of the 2
nd
line
Significance Output format
1-60
Measured value text
(optional)
Variable length
61, 62
Special characters,
CR and LF
Line feed
Table 3-84 Structure of the MSPRI evaluation block message, 2nd line
”01.05.1993 08:01:15:0045 P: 123 S: 10 Typ: W Nr: 25 -1.123456e+12 ms ”
”This is a message text”
Table 3-85 Example of a message output
NOTE
Overflow-, communication error- and system error messages have the
same logical structure as for block MSI.
Example of a
message output
