Communications configuring
System- and communication configuring D7-SYS - SIMADYN D 3-311
Edition 12.2003
CVP Connection with LI, connection CCV >LI.CCV
NOTE
In addition, the following must be configured: Central message block
@MSI, message output block MSI and the message block MERF0.
I/O name Significance Example
CMS Message system name MYMELD
CMT Message text (this is not output) ""
NOM No. of messages which can be saved 200
SAV Message buffer, buffered RAM 0
RP Prefix for communication errors 0
MUN Enable for message entries 1
I/O name Significance Example
CMS Message system name MYMELD
CTS Coupling module name D01_P1
AT Address parameter EMPFKANA
RP Prefix for overflow messages 0
SNV Output, message number 1
STM Output, message text 0
STC Output, message text constant length 1
SSF Output format 1
EN Enable 1
MUN Enable for message entries 1
FB @MSI
FB MSI
