Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-7
Edition 03.2001
STRUC
V.4.x
CFC with D7-
SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
LVM0F - ---
Eliminated; replaced (partially) by
LVM
LVM2F LVM --- ---
DUMY NOP1_I --- X, Y as "INT" (previously "N2")
- NOP8_I --- New;
DUMY1 NOP1_B --- ---
- NOP8_B --- New;
DUMY4 NOP1_D --- X, Y as "DINT" (previously "N4")
- NOP8_D --- New;
DUMYF NOP1 --- ---
- NOP8 --- New;
THEN - ---
Eliminated; replace (indirect) using
the sequence group
END - --- Eliminated; replace (indirect) using
the sequence group
PAS PAS --- ---
PAC0F1 PAC --- ---
PAI PAI --- ---
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-5 Changes in the logic blocks
