Siemens SIMATIC ET 200M

A-1
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
Order Numbers for the ET 200M
Components for the ET 200M
Table A-1 Components for the ET 200M
Accessories and Spare Parts for the ET 200M
Order Number
Active bus modules
 Bus module BM IM/IM (...7HD) for redundancy with
2 IM 153-2AA02/-2AB01
 Bus module BM IM/IM (...7HD) for redundancy with 2 IM 153-2Bx00
6ES7 195-7HD00-0XA0
6ES7 195-7HD10-0XA0
 Bus module BM PS/IM (...7HA) for power supply and IM 153 6ES7 195-7HA00-0XA0
 Bus module 2 40 (...7HB) for one or two S7-300 modules 40 mm
wide
6ES7 195-7HB00-0XA0
 Bus module 1 80 (...7HC) for an S7-300 module 80 mm wide 6ES7 195-7HC00-0XA0
Covers
(includes 4 backplane bus covers and 1 bus module cover)
6ES7 195-1JA00-0XA0
Explosion-proof partition 6ES7 195-1KA00-0XA0
Rail for the ”module change during operation” function
 482.6 mm
 530 mm
 620 mm
 2000 mm
6ES7 195-1GA00-0XA0
6ES7 195-1GF30-0XA0
6ES7 195-1GG30-0XA0
6ES7 195-1GC00-0XA0
Bus connector
 Up to 12 Mbaud
without programming port
with programming port
6ES7 972-0BA40-0XA0
6ES7 972-0BB40-0XA0
Interconnecting cable
 Normal 6XV1 830-0AH10
 Direct-buried cable 6XV1 830-3AH10
 Drum cable 6XV1 830-3BH10
 Festoon attachment for PROFIBUS bus system 6XV1 830-3CH10
Fiber-optic cable
 SIMATIC NET PROFIBUS Plastic Fiber Optic, Duplex core
(50 m ring)
6XV1 821-2AN50
A
