SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
109
Technical specifications
8
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The device is closed.
•
The I/O devices
fulfill the requirements for the respective area of application (interference
emission according to EN 61000-6-3 / IEC 61000-6-
3, interference immunity according to
EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note under "Validity of the technical specifications (Page 109)".
Article number 6AG4131-3....-.... (for details, refer to the ordering documenta-
tion)
Dimensions Device with two expansion slots:
295 × 265 × 93 (W × H × D in mm)
Device with five expansion slots:
295 x 265 x 155 (W × H × D in mm)
Weight Device with two expansion slots:
approx. 5 kg
Device with five expansion slots:
approx. 7 kg
Supply voltage AC Nominal 100-240 V AC (-15% / +10%) (wide range)
Supply voltage DC
1
Nominal 24 V DC (-20% / + 20%), SELV
1
Input current AC
Continuous current up to 1.7 A (up to 50 A for 1 ms at startup)
Input current DC
Continuous current up to 7.1 A (up to 13 A for 50 ms at startup)
Supply voltage frequency
50-60 Hz (47 to 63 Hz)
Short-term voltage interruption in
accordance with Namur
max. 20 ms (at 93 to 264 V)
(max. 10 events per hour; recovery time at least 1 s)
Max. power consumption AC and
DC
Active power 176 W
Noise emission
< 55 dB(A) according to EN ISO 7779
Degree of protection
IP 20 to IEC 60529
Quality assurance
In accordance with ISO 9001
