Technical specifications
8.7 Technical specifications of the motherboard
SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
117
8.7 Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 109)".
Processor
• Intel® Celeron® G4900 2 cores/2 threads,
3.1 GHz, 2 MB cache, VT
• Intel® Core™ i3-8100 4 cores/4 threads,
3.6 GHz, 6 MB cache, VT
• Intel® Core™ i7-8700 6 cores/12 threads,
3.2 (4.6) GHz, 12 MB cache, VT, iAMT
Main memory 4 up to 64 GB, DDR4 SDRAM,
see ordering documents for features
Expansion slots IPC627E Version with
• 2 expansion slots
or
• 5 expansion slots
Maximum bandwidth of PCI slots
Maximum bandwidth of PCI slots
Rev. 3.0: 8 GT/s (985 Mbps) bandwidth per lane
Max. permissible power loss per
Total power consumption (all voltages) may not exceed 25 W.
Expansion card slots
Expansion card slots IPC627E with
expansion slots
PCI: Specification Rev. 2.3, length: Max. 185 mm
PCI: Specification Rev. 2.3, length: Max. 185 mm
Expansion card slots IPC627E with
expansion slots
(bus module 1 x PCI and 1 x PCIexpress (x16))
PCI: Specification Rev. 2.3, length: Max. 185 mm
PCIexpress x16: Specification Rev. 3.0, length: Max. 185 mm
Expansion card slots IPC627E with
expansion slots
(bus module 2 x PCIexpress (x16, x4))
PCIexpress x4: Specification Rev. 3.0, length: max. 185 mm
PCIexpress x16: Specification Rev. 3.0, length: max. 185 mm
Expansion card slots IPC627E with
expansion slots
(bus module 3 x PCI (x1), 1 x PCIexpress (x4) and 1x PCIexpress (x16))
PCI: Specification Rev. 2.3, length: max. 240 mm
PCI: Specification Rev. 2.3, length: max. 240 mm
PCI: Specification Rev. 2.3, length: max. 185 mm
PCIexpress x4: Specification Rev. 3.0, length: max. 185 mm
PCIexpress x16: Specification Rev. 3.0, length: max. 185 mm
