Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
49
3.3.3.2 Connecting the 24 VDC power supply
Safety regulations - connecting cable
Use only AC or DC connecting cables which comply with the local safety regulations.
Otherwise, there is a risk of fire and electric shock. This can result in personal injury or
property damage.
• Ensure that the AC or DC connecting cables comply with the safety regulations of the
country in which the device is installed and bear the marks required in each case.
• Connect the protective conductor in accordance with the operating instructions.
The on/off button and on/off switch do not fully disconnect the device from the supply
voltage.
There is also a risk of fire if the device or connecting lines are damaged.
• Always fully disconnect the device from the supply voltage before performing work on
the device or when the device will not be used over an extended period of time.
• For control cabinet mounting: Use a central, easily accessible AC circuit breaker close
to the device, if possible.
• When you install the device, make sure that the power supply connector is easily
accessible.
Note
Safety extra-low voltage (SELV)
•
The device must only be connected to a 24 V DC power supply which meets the
requirements of safe extra-low voltage (SELV) according to IEC/EN/DIN EN/UL 61010-2-
201. A protective conductor must also be used.
The conductors must withstand the short-circuit current of the 24 V DC power source, so
that a short-circuit will not damage the cable.
Only connect cables with a minimum cross-section of 1.3 mm
2
(AWG16) and a maximum
cross-section of 3.3 mm
2
(AWG12).
Requirements
● You have observed the information under "Country-specific information on supply voltage
(Page 45)".
● The 24 V DC power source must be adapted to the input data of the device
(see Technical specifications (Page 109)).
