Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
51
3.3.4 Connecting I/O devices
Fault caused by I/O devices
The improper connection of I/O devices can cause faults in the device.
The result may be personal injury and damage to the machine or plant.
• You should observe the warnings relating to the connection of I/O devices in
"Information on I/O devices (Page 33)".
Procedure
Note
Use the original connections of the I/O to be connected
without adapters or extensions.
1. Connect the I/O devices to the respective interfaces.
Information on the position of the interfaces is available in "Front panel (Page 16)".
2. Secure the cables with the strain relief.
See: Connecting Ethernet/USB strain relief (Page 54)
