Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC627E
52 Operating Instructions, 12/2018, A5E44297201-AA
Connecting several monitors (multi-monitoring)
You will find up to three ports on the rear of the device for connecting monitors. These ports
are connected to the motherboard.
Parameter assignment is performed by means of the Control Panel in Windows®.
The IPC is factory set for multi-monitoring. If needed, you can configure the multi-monitoring
function and the output of the boot screen in the firmware settings, see "Multi-monitoring
(Page 59) ".
The following table shows the various connection options for the monitors on the device
interfaces.
Motherboard
DPP1
DPP2
DVI-D
Monitor 1
DP
X
-
-
DVI
X
1)
-
-
VGA X
2)
- -
Monitor 2
DP
-
X
-
DVI
-
X
1)
-
VGA
-
X
2)
-
Monitor 3
DP
-
-
-
DVI
-
-
X
VGA
-
-
-
1)
- via DP to DVI-D adapter
2) - via DP-VGA adapter
