Device maintenance and repair
7.3 Removing and installing hardware
SIMATIC IPC627E
90 Operating Instructions, 12/2018, A5E44297201-AA
7.3 Removing and installing hardware
7.3.1 Replacing device fans
Requirement
● The device is disconnected from the mains and all connecting cables have been
removed.
● The device is open, see important information regarding this under Opening the Device
(Page 71).
● An original spare part, that is a fan of the same type, see information under Accessories:
Hardware (Page 24).
Procedure - Removal
1. Remove the two screws ① and remove the air guide pulling it up vertically.
2. Loosen the plastic rivets.
