Device maintenance and repair
7.3 Removing and installing hardware
SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
93
7.3.2 Replace power supply fan
Requirements
● The device is disconnected from the voltage supply and all connecting cables have been
unplugged.
● The device is open, see important information regarding this under Opening the Device
(Page 71).
● An original spare part, that is a fan of the same type, see information under Accessories:
Hardware (Page 24).
Procedure - Removal
1. Remove the four plastic rivets on the enclosure and remove the marked screw ①.
2. Pull the power supply connector and remove the marked screws.
