Siemens SIMATIC IPC627E User Manual

Hardware description
A.4 External interfaces
SIMATIC IPC627E
142 Operating Instructions, 12/2018, A5E44297201-AA
A.4 External interfaces
Note
Interface specification
The data of all external interfaces listed below correspond to the respective interface
specifications and the intended use.
Interface
Connector
Description
Assignment
COM1 X30 9-pin D-sub connector
(± 12 V)
USB 3.1 X60, X62
X64, X65
USB 3.1 female connector Type A
(5 V; 900 mA; up to 10 Gbps)
USB 3.1 type C X61, X63 USB 3.1 female connector Type C
(5 V; 1.5 A to 3.0 A; up to 10 Gbps)
Ethernet 1, 2 and
3
X1P1,
X2P1,
X3P1
RJ45
(up to 1 Gbps)
DVI-D X70 24-pin DVI-D female connector
(5 V; 500 mA)
DPP X71, X72 20-pin DisplayPort connector
(3.3 V; 500 mA)
