Hardware description
A.2 Internal interfaces
SIMATIC IPC627E
Operating Instructions, 12/2018, A5E44297201-AA
137
A.2 Internal interfaces
A.2.1 Pin assignment of the internal interfaces
Socket for bus expansion, assigned PCI bus signals
20-pin connector plug for power supply
BIOS Recovery Internal Jumper:
• Jumper on pins 2-3: default
• Replug to pins 3-4 for BIOS Recovery
*
• Replug to pins 1-2 for ME Update
*
*
A special USB stick is required for this (not included in scope of
delivery; contact your local SIEMENS representative)
Serial ATA, max. 2 /4 drives operable
Connection for PS
Internal Voltage supply for serial ATA
Voltage supply for CPU fan, 4-pin male connector
Connection for equip-
Internal Voltage supply for equipment fan, 4-pin male connector
Voltage supply for backup battery, 2-pin male connector
USB port Internal USB channel 6 and 7, 10-pole male connector
on expansion card (optional) guided
USB channel 9, upright USB socket
A.2.2 Device fan supply (X512)
