Hardware description
A.3 Bus board
SIMATIC IPC627E
140 Operating Instructions, 12/2018, A5E44297201-AA
Version 3 (IPC627E; 2 slots)
①
Slot 1 PCI Express x4 (mechanical x16)
②
Slot 1 PCI Express x16
③
12 V power supply connection; see Pin assignment 12 V power supply connection for expan-
sion cards (Page 141)
Version 4 (IPC627E; 5 slots)
①
Slot 1/2/3 PCI
②
Slot 4 PCI Express x4 (mechanical x16)
③
Slot 5 PCI Express x16
④
12 V power supply connection; see Pin assignment 12 V power supply connection for expan-
sion cards (Page 141)
