Siemens SIMATIC IPC647D

Technical specifications
8.6 BIOS description
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
183
Display
(hex)
Meaning
Description
Remedy
5DH DXE_SB_IOTRAP_INIT Setup SB IOTRAP
Service
SouthBridge IOTRAP
service
Service case
5EH DXE_SUBCLASS_DRIVER Build AMT Table Initialization of the AMT
(Active Management
Technology) table
Service case
5FH DXE_PPM_INIT PPM Initial Initialization of the
Processor Power
Management
Service case
60H DXE_HECIDRV_INIT HECIDRV Initial Initialization of the Host
Embedded Controller
Interface
Service case
61H DXE_VARIABLE_RECLAIM Variable store garbage
collection and reclaim
operation
Loading of the variable
memory
Service case
10H BDS_ENTER_BDS Enter BDS entry Phase Boot Device
Selection
Service case
11H BDS_INSTALL_HOTKEY Install Hotkey service Installation of the Hotkey
service
Service case
12H BDS_ASF_INIT ASF Initial Initialize Alert Standard
Format
Service case
13H
BDS_PCI_ENUMERATION_START
PCI enumeration
Enumerate PCI bus
Service case
14H BDS_BEFORE_PCIIO_INSTALL PCI resource assign
complete
Assign PCI resources Run a test by
disabling the
hardware
components in
SETUP, or by
removing the
expansion
modules
installed on
the bus
module.
15H BDS_PCI_ENUMERATION_END PCI enumeration
complete
PCI enumeration
completed
Service case
16H BDS_CONNECT_CONSOLE_IN Keyboard Controller,
Keyboard and Mouse
initial
Initialization of keyboard
and mouse
Run a test by
replacing the
keyboard/mou
se
17H BDS_CONNECT_CONSOLE_OUT Video device initial Initialize graphic
connection
Service case
18H BDS_CONNECT_STD_ERR Error report device initial Initialize default error
output
Service case
19H BDS_CONNECT_USB_HC USB host controller initial Initialize USB host
controller
Service case
1AH
BDS_CONNECT_USB_BUS
USB BUS driver initial
Initialize USB bus driver
Service case
1BH BDS_CONNECT_USB_DEVICE USB device driver initial Initialize USB device
driver
Service case
1CH BDS_NO_CONSOLE_ACTION Console device initial fail Initialization of the console
faulty
Service case
