Siemens SIMATIC IPC647D

Technical specifications
8.6 BIOS description
SIMATIC IPC647D
184 Operating Instructions, 01/2014, A5E32996306-AA
Display
(hex)
Meaning
Description
Remedy
1DH BDS_DISPLAY_LOGO_SYSTEM_INFO Display logo or system
information
Display logo or system
information
Service case
1EH BDS_START_IDE_CONTROLLER IDE controller initial Initialization of the IDE
controller
Service case
1FH BDS_START_SATA_CONTROLLER SATA controller initial Initialization of the SATA
controller
Service case
20H BDS_START_ISA_ACPI_CONTROLLER SIO controller initial Initialization of the Super
IO
Service case
21H BDS_START_ISA_BUS ISA BUS driver initial Initialization of the ISA bus
driver
Service case
22H BDS_START_ISA_FDD Floppy device initial Initialization of the floppy
connection
Service case
23H BDS_START_ISA_SERIAL Serial device initial Initialization of the serial
connection
Service case
24H BDS_START_IDE_BUS IDE device initial Initialization of the IDE
connection
Service case
25H BDS_START_AHCI_BUS AHCI device initial Initialization of the AHCI
connection
Service case
26H BDS_CONNECT_LEGACY_ROM Dispatch option ROMs Callup of the Legacy
Option ROMs
Service case
27H BDS_ENUMERATE_ALL_BOOT_OPTIO
N
Get boot device
information
Determine the Boot
Device information
Service case
28H
BDS_END_OF_BOOT_SELECTION
End of boot selection
Boot selection terminated
Service case
29H
BDS_ENTER_SETUP
Enter Setup Menu
Callup into SETUP
Service case
2AH
BDS_ENTER_BOOT_MANAGER
Enter Boot manager
Callup Boot Manager
Service case
2BH
BDS_BOOT_DEVICE_SELECT
Try to boot system to OS
Booting of the OS
Service case
2CH BDS_EFI64_SHADOW_ALL_LEGACY
_ROM
Shadow Misc Option
ROM
Copying the Legacy
Option ROMs into RAM
Service case
2DH BDS_ACPI_S3SAVE Save S3 resume required
data in RAM
Make available for
operating state S3 RAM
Service case
2EH BDS_READY_TO_BOOT_EVENT Last Chipset initial before
boot to OS
Initialization of the last
chipset before the OS
Boot
Service case
2FH
BDS_GO_LEGACY_BOOT
Start to boot Legacy OS
Boot Legacy OS
Service case
30H
BDS_GO_UEFI_BOOT
Start to boot UEFI OS
Boot UEFI OS
Service case
31H BDS_LEGACY16_PREPARE_TO
_BOOT
Prepare to Boot to
Legacy OS
Preparation for booting of
Legacy OS
Service case
32H BDS_EXIT_BOOT_SERVICES Send END of POST
Message to ME via HECI
Terminate Boot Service Service case
33H BDS_LEGACY_BOOT_EVENT Last Chipset initial before
boot to Legacy OS.
Initialization of the last
chipset before the Legacy
OS Boot
Service case
34H BDS_ENTER_LEGACY_16_BOOT Ready to Boot Legacy
OS.
Callup to boot the Legacy
OS
Service case
35H BDS_RECOVERY_START_FLASH Fast recovery start flash Start the BIOS Recovery
function
Service case
