Siemens SIMATIC IPC647D

Technical specifications
8.6 BIOS description
SIMATIC IPC647D
Operating Instructions, 01/2014, A5E32996306-AA
185
Display
(hex)
Meaning
Description
Remedy
F9H POST_BDS_NO_BOOT_DEVICE No Boot Device,
PostBDS_NO_BOOT_DE
VICE
No BOOT device found Service case
FBH POST_BDS_START_IMAGE UEFI Boot Start Image,
PostBDS_START_IMAG
E
Booting of an UEFI image Service case
FDH
POST_BDS_ENTER_INT19
Legacy 16 boot entry
Start Legacy 16 boot
Service case
FEH
P0ST_BDS_JUMP_BOOT_SECTOR
Try to Boot with INT 19
Boot with INT 19
Service case
E4H ASL_WAKEUP_S4 System wakeup from S4 Reboot from operating
state S4
Service case
E5H ASL_WAKEUP_S5 System wakeup from S5 Reboot from operating
state S5
Service case
Note
If the boot process is interrupted with a BIOS POST message output on the screen, you will
hear three long beeps. The parameter "POST Errors" must, for example, be set to "Halt on
all errors" in the BIOS setup
menu "Advanced > Boot Configuration" for this.
Special codes
Only the following BIOS post message is output as beep code:
● No RAM: 3 long beeps followed by 2 short beeps, repeated for a total of three times.
