Technical specifications
8.4 Technical data
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA
123
Electromagnetic compatibility (EMC)
Radiated interference (AC) EN 61000-6-3, FCC Class A
EN 61000-6-4;
CISPR 22,EN 55022 class B
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity: Conducted
disturbance variables on supply lines
± 2 kV, (to IEC 61000-4-4; Burst)
± 1 kV; (to IEC 61000-4-5; Surge symm.)
± 2 kV; (to IEC 61000-4-5; Surge asymm.)
Noise immunity on signal lines ± 1 kV;(according to IEC 61000-4-4; Burst; Length < 30 m)
± 2 kV; (according to IEC 61000-4-4; Burst; Length > 30 m)
± 2 kV; (according to IEC 61000-4-5; Surge; Length > 30 m)
Immunity to discharge of static
± 6 kV contact discharge; (to IEC 61000-4-2)
± 8 kV air discharge; (to IEC 61000-4-2)
Immunity to RF interference 10 V/m, 80 to 1000 MHz and 1.4 to 2 GHz, 80% AM
(to IEC 61000-4-3)
3 V/m 2 - 2.7 GHz, 80% AM (to IEC 61000-4-3)
10 V, 10 KHz to 80 MHz; 80% AM; (to IEC 61000-4-6)
100 A/m, 50 Hz / 60 Hz; (to IEC 61000-4-8)
Tested to:
IEC 60068-2-2, IEC 60068-2-1, IEC 60068-2-14
- Operation
• + 5 °C to + 45 °C no burner operation
• + 5 °C to + 50 °C no optical drive operation
Power loss of the expansion cards in total less than
30 W, maximum 3 removable drive bays
• Gradient: Max. 10 °C/h, no condensation
- Storage/shipping
• - 20°C to + 60°C
• Gradient: Max. 20 °C/h, no condensation
Tested to IEC 60068-2-78, IEC 60068-2-30
- Operation
• 5% to 80% at 25 °C (no condensation)
• Gradient: Max. 10 °C/h, no condensation
- Storage/shipping
• 5% to 95% at 25 °C (no condensation)
• Gradient: Max. 20 °C/h, no condensation
- Operation 1080 to 795 hPa
(corresponds to an altitude of -1000 to 2000 m)
- Storage / shipping 1080 to 660 hPa
(corresponds to an altitude of -1000 to 3500 m)
Vibration
- Operation
1, 2
Tested to IEC 60068-2-6, 10 cycles
10 to 58 Hz: 0.0375 mm, 58 Hz to 500 Hz: 4.9 m/s
2
5 to 9 Hz: 3.5 mm, 9 to 500 Hz: 9.8 m/s
2
