Technical specifications
8.5 Hardware description
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA
149
Pin assignment of fan interface X512, X513, X515
Pin no.
Short name
Meaning
Input / output
1
GND
Ground
-
2
VCC
+12 V fused
Output
3
Tacho signal
Monitoring signal
Input
4
PWM
Speed setting
Output
Pin assignment of the supply for the serial ATA drives X516, 517, 518, 519, 520, 521
Pin no.
Short name
Meaning
Input / output
1
+12 V
Power supply
Output
2
GND
Ground
–
3
GND
Ground
–
4
+5 V
Power supply
Output
5
+3.3 V
Power supply
Output
Pin assignment of the PEG interface (PCIe X16 socket), X610
Signal
Pin no.
Pin no.
Signal
P12V
B1
A1
P12V
P12V
B2
A2
P12V
P12V
B3
A3
P12V
GND
B4
A4
GND
SMB_CLK2
B5
A5
n.c.
SMB_DATA2
B6
A6
n.c.
GND
B7
A7
n.c.
P3V3 B8 A8 n.c.
n.c.
B9
A9
P3V3
AUX_3V
B10
A10
P3V3
WAKE2
B11
A11
PCIE_RESET_L
n.c.
B12
A12
GND
GND
B13
A13
PCIE0_ECLK
PCIEX16_TX_P(15)
B14
A14
PCIE0_ECLK_N
PCIEX16_TX_N(15)
B15
A15
GND
GND
B16
A16
PCIEX16_RX_P(15)
SDVO_CTRLCLK
B17
A17
PCIEX16_RX_N(15)
GND
B18
A18
GND
PCIEX16_TX_P(14)
B19
A19
n.c.
PCIEX16_TX_N(14)
B20
A20
GND
GND
B21
O21
PCIEX16_RX_P(14)
