8.6 BIOS description
SIMATIC IPC847D
186 Operating Instructions, 01/2014, A5E32997454-AA
Display
(hex)
Meaning
Description
Remedy
31H BDS_LEGACY16_PREPARE_TO_B
OOT
Prepare to Boot to Legacy
OS
Preparation for booting of
Legacy OS
Service case
32H BDS_EXIT_BOOT_SERVICES Send END of POST
Message to ME via HECI
Terminate Boot Service Service case
33H BDS_LEGACY_BOOT_EVENT Last Chipset initial before
boot to Legacy OS.
Initialization of the last
chipset before the Legacy
OS Boot
Service case
34H BDS_ENTER_LEGACY_16_BOOT Ready to Boot Legacy OS. Callup to boot the Legacy
OS
Service case
35H BDS_RECOVERY_START_FLASH Fast recovery start flash Start the BIOS Recovery
function
Service case
F9H POST_BDS_NO_BOOT_DEVICE No Boot Device,
PostBDS_NO_BOOT_DEVI
CE
No BOOT device found Service case
FBH POST_BDS_START_IMAGE UEFI Boot Start Image,
PostBDS_START_IMAGE
Booting of an UEFI image Service case
FDH
POST_BDS_ENTER_INT19
Legacy 16 boot entry
Start Legacy 16 boot
Service case
FEH P0ST_BDS_JUMP_BOOT_SECTOR Try to Boot with INT 19 Boot with INT 19 Service case
E5H ASL_WAKEUP_S5 System wakeup from S5 Reboot from operating state
S5
Service case
10H BDS_ENTER_BDS Enter BDS entry Phase Boot Device
Selection
Service case
11H BDS_INSTALL_HOTKEY Install Hotkey service Installation of the Hotkey
service
Service case
12H BDS_ASF_INIT ASF Initial Initialize Alert Standard
Format
Service case
13H
BDS_PCI_ENUMERATION_START
PCI enumeration
Enumerate PCI bus
Service case
14H BDS_BEFORE_PCIIO_INSTALL PCI resource assign
complete
Assign PCI resources
Run a test by disabling the hardware
components in SETUP, or by removing the
expansion modules installed on the bus
module.
15H
BDS_PCI_ENUMERATION_END
PCI enumeration complete
PCI enumeration completed
Service case
16H BDS_CONNECT_CONSOLE_IN Keyboard Controller,
Keyboard and Mouse initial
Initialization of keyboard
and mouse
Run a test by
replacing the
keyboard/mo
use
17H BDS_CONNECT_CONSOLE_OUT Video device initial Initialize graphic connection Service case
18H
BDS_CONNECT_STD_ERR
Error report device initial
Initialize default error output
Service case
19H BDS_CONNECT_USB_HC USB host controller initial Initialize USB host controller Service case
1AH
BDS_CONNECT_USB_BUS
USB BUS driver initial
Initialize USB bus driver
Service case
1BH
BDS_CONNECT_USB_DEVICE
USB device driver initial
Initialize USB device driver
Service case
1CH BDS_NO_CONSOLE_ACTION Console device initial fail Initialization of the console
faulty
Service case
1DH BDS_DISPLAY_LOGO_SYSTEM_IN
FO
Display logo or system
information
Display logo or system
information
Service case
