Siemens SIMATIC MOBY D User Manual

Mobile data storage units
5.6 MDS D160
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
119
5.6.4 Technical specifications
Memory size 128 bytes
Memory configuration
 Serial number
 Configuration memory
 Application memory
 8 bytes (fixed code)
 8 bytes
 112 bytes
Storage technology EEPROM
Memory organization EEPROM 128 bytes gross
112 bytes net capacity
When using the OPT area, 16 bytes of it must be
subtracted in 4 byte blocks
Protocol According to ISO 15693
Data retention (at +55 °C) 10 years
MTBF (at +40 °C) 2 x 10
6
hours
Bulk detection/multitag capability Yes
Data retention 10 years
Read cycles Unlimited
Write cycles at + 40 °C, typical 1 000 000
Write cycles, min. 100 000
Read/write distance (S
g
) See Chapter Field data (Page 33)
Distance from metal Min. 25 mm (approx. 30% reduction of the field
data)
Power supply Inductive power transmission
(without battery)
Degree of protection to EN 60529 IP68 (24 hours, 2 m, +20 °C)
Shock, tested in accordance with IEC 68-2-27 40 g
(18 ms; 6 axes; 2000 repeats/h)
Vibration, tested in accordance with IEC 68-2-6 10 g
(10 to 2000 Hz; 3 axes; 2.5 h)
Torsion and bending load Not permissible
Mechanical strength
 Isostatic pressure
 Axial pressure
 Radial pressure
 300 bar for 5 min
 1000 N for 10 s
 1000 N for 10 s
Resistance to chemicals All chemicals normally used in the washing
process
MDS lifespan At least 100 wash cycles
Mechanical design
 Color
 Material
 Dimensions (D x H) in mm
 White
 PPS, pressed, impact-resistant plastic
 16(±0.2) x 3,0(±0.2)
MDS fixing Patch, sew, glue
