Siemens SIMATIC MOBY D User Manual

System integration
9.3 ASM 473
MOBY D
250 System Manual, 01/2010, J31069-D0147-A6-7618
9.3.6 Technical data
Table 9- 6 Technical specifications for ASM 473
Interface for ET 200X SIMATIC S7 I/O bus
cyclic/acyclic services
Communication 2 words cyclic/238 bytes acyclic
Command buffer in ASM 142 x 238 bytes
Serial interface to write/read device
 Connectors
 Max. cable length
 Connectable SLGs
 2 x M12 coupler plug
 2 m = standard length; other pre-assembled
cables = 5 m, 20 m (up to 1000 m on request)
 1 x SLG D1xS with RS 422
Connectors 2 x M12 coupler plug
Max. cable length 2 m = standard length; other pre-assembled
cables = 5 m, 20 m (up to 1000 m on request)
Connectable SLGs 1 x SLG D1xS with RS 422
Software functions
Programming Depending on the PROFIBUS DP master
Function blocks for SIMATIC S7 FC 45
MDS addressing Direct access via addresses
Commands Initialize MDS, read data from MDS, write data to
MDS, etc.
PROFIBUS DP diagnostics Yes; in accordance with ET 200X basic station
S7 diagnostics Yes, can be called up via S7 OM
Reloadable firmware Yes, via S7 OEM
Power supply
1
 Rated value
 Permitted range
 24 V DC
 20.4 V to 28.8 V DC
Current consumption Typ. 75 mA; max. 500 mA
(or see Technical Data of the connected SLG)
Power dissipation of the module Typ. 1.6 W
Digital outputs/inputs Via expansion modules from the ET 200X
spectrum
Ambient temperature
 Operation
 Transport and storage
 0 to +55°C
 -40 to +70°C
Dimensions (W x H x D) in mm
 Single unit
 Width module
 87 x 110 x 55
 60 x 110 x 55
Mounting technique 2 M5 screws (customer side)
2 M3 screws (product side)
Degree of protection IP67
