Planning the MOBY D system
4.2 Field data
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
37
4.2.2 Minimum spacing
Table 4- 10 Minimum distance from MDS to MDS (without multitag mode)
MDS D100 / MDS D139 /
MDS D165 / MDS D200 /
MDS D261
MDS D124 / MDS D160 /
MDS D324 / MDS D424 /
MDS D428 / MDS D460
ANT D5 ≥ 1 m ≥ 0.8 m
ANT D6 ≥ 1.5 m ≥ 1.2 m
SLG D10/D10S
ANT D10 ≥ 2 m ≥ 1.8 m
ANT D2
 Horizontal main field
 Vertical main field
--
--
≥ 0.4 m
≥ 0.1 m
SLG D11/D11S
ANT D5 ≥ 1 m ≥ 0.8 m
SLG D12/SLG D12S/
SLG D12S
(plug-in version)
≥ 0.3 m ≥ 0.5 m
Reduction of the minimum spacing in multitag mode is permitted
(SLG D10/SLG D11/SLG D12, RS232).
Table 4- 11 Minimum distance from SLG to SLG (antennas)
SLG D10/
SLG D10S
SLG D11/
SLG D11S
SLG D12/
SLG D12S/
SLG D12S
(plug-in version)
ANT D5 ANT D6 ANT D10 ANT D2 ANT D5
ANT D5 ≥ 2 m ≥ 2 m ≥ 2 m ≥ 1 m ≥ 2 m ≥ 1 m
ANT D6 ≥ 2 m ≥ 2 m ≥ 2 m ≥ 1 m ≥ 2 m ≥ 1 m
SLG D10/
SLG D10S
ANT D10 ≥ 2 m ≥ 2 m ≥ 2 m ≥ 1 m ≥ 2 m ≥ 1 m
ANT D2 ≥ 1 m ≥ 1 m ≥ 1 m ≥ 0.5 m ≥ 0.8 m ≥ 0.8 m SLG
D11/SLG
D11S
ANT D5 ≥ 2 m ≥ 2 m ≥ 2 m ≥ 0.8 m ≥ 2 m ≥ 1 m
SLG D12/SLG D12S/
SLG D12S
(plug-in version)
≥ 1 m ≥ 1 m ≥ 1 m ≥ 0.8 m ≥ 1 m ≥ 1 m
NOTICE
Extension of the data transmission time if distance values are undershot
If the distance values specified in the tables are undershot, it is possible that the inductive
fields will be affected. In this case, the data transmission time can increase unpredictably or
a command is aborted with an error.
For this reason, please observe the values in the tables.
