Planning the MOBY D system
4.2 Field data
MOBY D
36 System Manual, 01/2010, J31069-D0147-A6-7618
SLG D12/D12S/D12S plug-in version
Table 4- 9 SLG D12/D12S
Length of the transmission window Operating distance
(S
a
)
Limit distance (S
g
)
in the X direction
(L
x
)
in the Y direction
(L
y
)
MDS D100 120 60 0...160 220
MDS D124 120 60 0...70 100
MDS D139 120 60 0...120 150
MDS D160 120 60 0...45 65
MDS D324 120 60 0...60 80
MDS D424 120 60 0...70 100
MDS D428 120 60 0...40 60
MDS D460 120 60 0...40 60
MDS D165 120 60 0...120 150
MDS D200 120 60 0...120 160
MDS D261 120 60 0...100 140
All values are in mm
