Siemens SIMATIC MOBY D User Manual

Antennas
8.2 ANT D5
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
211
8.2.3 Technical data
Table 8- 6 Technical specifications for ANT D5
Max. write/read distance
ANT to MDS (S
g
)
480 mm
1)
Dimensions in mm (L x W x H) 340 x 325 x 38
Color Black
Material Plastic ASA
Plug connection 1-pin TNC connector
Max. power 10 W (FCC/IC:4 W)
Antenna cable length 3.6 m
Shock resistant according to EN 60721-3-7
Class 7M2
Total shock response spectrum Type II
30 g
Vibration according to EN 60721-3-7 Class
7M2
1 g (9 to 200 Hz)/1.5 g (200 to 500 Hz)
Attachment of the antenna 4 x M5 screws
Ambient temperature
 Operation
 Transport and storage
 -20 °C to +55 °C
 -25 °C to +70 °C
MTBF 3 x 10
5
hours
Degree of protection according to EN 60529 IP65 (UL: for indoor use only)
Weight, approx. 1 kg
Approvals
 CE
 FCC
 IC
 Harmless to heart pacemakers
 UL 60950
1)
In order to ensure optimum field data even in the vicinity of metal, ANT D5 is calibrated at the factory at a distance of
100 mm from metal (see the accessory "Spacer kit" in the ordering data section).
