Siemens SIMATIC MOBY D - Technical Specifications

Mobile data storage units
5.13 MDS D460
MOBY D
146 System Manual, 01/2010, J31069-D0147-A6-7618
5.13.4 Technical specifications
Memory size 2048 bytes
Memory configuration
 Serial number
 Configuration memory
 Application memory
 8 bytes (fixed code)
 40 bytes
 2000 bytes
Storage technology FRAM
Memory organization 2048 bytes gross
2000 bytes net
Protocol ISO 15693
Data retention (at +40 °C) 10 years
MTBF (at +40 °C) 2 x 10
6
hours
Bulk detection/multitag capability Yes
Read cycles Unlimited
Write cycles (at +40 °C, typical) > 10
10
Read/write distance (S
g
) See Chapter Field data (Page 33)
Distance from metal Min. 15 mm (ca. 20% reduction of the field data)
Power supply Inductive power transmission
(without battery)
Degree of protection to EN 60529 IP67
IPx9K
1)
Shock, tested in accordance with IEC 68-2-27 50 g
2)
Vibration, tested in accordance with IEC 68-2-6 20 g
2)
Torsion and bending load Not permissible
Enclosure
 Color
 Material
 Dimensions (D x H) in mm
 Black
 Epoxy casting resin
 16(±0.2) x 3,0(±0.2)
MDS fixing Adhesion, spacer
Ambient temperature
 During operation
 Transport and storage
 -25 °C to +85 °C permanent
 -40 °C to +100 °C
Weight, approx. 3 g
1)
steam jet: 150 mm; 10 to 15 l/min; 100 bar; 75 °C
2)
The values for shock and vibration are maximum values and must not be applied continuously.
