Planning the MOBY D system
4.2 Field data
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
35
SLG D11/D11S with ANT D2
Table 4- 7 SLG D11/D11S with ANT D2
Length of the transmission
window (L)
Operating distance (S
a
) Limit distance (S
g
)
MDS D124 60 45...70 90
MDS D160 50 35...55 65
MDS D324 50 35...60 70
MDS D424 60 45...70 90
MDS D460 50 30...50 60
All values are in mm
SLG D11/D11S with ANT D5
Table 4- 8 SLG D11/D11S with ANT D5
Diameter of the
transmission window (L
d
)
Operating distance (S
a
) Limit distance (S
g
)
MDS D100 ∅ 300 0...300 380
MDS D124 ∅ 280 0...150 220
MDS D139 ∅ 300 0...280 350
MDS D160 ∅ 280 0...75 110
MDS D324 ∅ 280 0...120 160
MDS D424 ∅ 280 0...150 200
MDS D428 ∅ 280 0...70 100
MDS D460 ∅ 280 0...70 100
MDS D165 ∅ 300 0...220 300
MDS D200 ∅ 300 0...220 320
MDS D261 ∅ 300 0...200 280
All values are in mm
