Siemens SIMATIC MOBY D User Manual

Planning the MOBY D system
4.2 Field data
MOBY D
34 System Manual, 01/2010, J31069-D0147-A6-7618
SLG D10/D10S with ANT D6
Table 4- 5 SLG D10/D10S with ANT D6
Length of the transmission window Operating distance
(S
a
)
Limit distance (S
g
)
in the X direction
(L
x
)
in the Y direction
(L
y
)
MDS D100 520 420 0...550 650
MDS D124 500 400 0...220 300
MDS D139 520 420 0...500 600
MDS D160 500 400 0...130 180
MDS D324 500 400 0...200 280
MDS D424 500 400 0...220 300
MDS D428 500 400 0...100 150
MDS D460 500 500 0...100 150
MDS D165 520 420 0...400 500
MDS D200 520 420 0...500 600
MDS D261 520 420 0...350 400
All values are in mm
SLG D10/D10S with ANT D10
Table 4- 6 SLG D10/D10S with ANT D10
Length of the transmission window Operating distance
(S
a
)
Limit distance (S
g
)
in the X direction
(L
x
)
in the Y direction
(L
y
)
MDS D100 1050 350 0...500 600
MDS D124 1000 300 0...200 280
MDS D139 1050 350 0...450 550
MDS D160 1000 300 0...130 180
MDS D324 1000 300 0...200 280
MDS D424 1000 300 0...200 280
MDS D428 1000 300 0...100 150
MDS D460 1000 300 0...100 150
MDS D165 1050 350 0...350 450
MDS D200 1050 350 0...450 550
MDS D261 1050 350 0...300 400
All values are in mm
