Alarm, error and system messages
11.2 Error messages and causes for MOBY D with ASM and FC/FB 45 (direct MDS addressing)
MOBY D
286 System Manual, 01/2010, J31069-D0147-A6-7618
Error code in
HEX
Flashing of
ERR LED
Cause, remedy
14 20x Internal ASM error or SLG error (watchdog)
 Program sequence error on the ASM
 Switch 24 V supply off and on again
 Program sequence error on the SLG
 Start init_run command after error correction.
15 21x Wrong parameterization of the ASM/SLG
 Check INPUT parameters in UDT 10.
 RESET command is parameterized incorrectly.
 After a start-up, the ASM has still not received an init_run.
16 22x The command cannot be processed with the current bus configuration.
 Input or output areas too small for the specified message frame
length.
Was the correct GSD file used?
 Write or read command issued with length specification too large.
Data length > 233 bytes.
 Change the configuration of the bus in the master module
17 23x Communication error between FC/FB 45 and MOBY-ASM.
Handshake error
 Params_DB (UDT 10) of this ASM station is being overwritten by
other parts of the program.
 Check parameters of MOBY ASM in UDT 10
 Check FC/FB 45 command which caused this error
 Start init_run command after error correction.
18 24x An error has occurred which must be acknowledged with an init_run.
 A temporary short circuit has occurred on PROFIBUS DP.
 The RESET command is faulty.
 Start init_run command after error correction.
19 25x Previous command is active or buffer overflow.
The user sent a new command to the ASM/SLG even though the last
command was still active.
 Active command can only be terminated with an init_run.
 Before a new command can be started the READY bit must be 1
(exception: init_run).
 Two FC/FB 45 calls were parameterized with the same parameters
("ASM_address" and "ASM_channel")
 Two FC/FB 45 calls are using the same Params_DB pointer
 Start init_run command after error correction.
 When command repetition (e.g., fixed code MDS) is used, no data
are fetched from the MDS. The data buffer on the ASM has
overflowed. MDS data have been lost.
