C.1 Previous MDS version with different MLFB
MOBY D
308 System Manual, 01/2010, J31069-D0147-A6-7618
Ambient temperature
 Operation
 Transport and storage
 -25 °C to
+100 °C
 +140 °C
 +200 °C
3

+
220 °C
 -40 °C to +100
°C
 permanent
 20% reduction in the limit
distance
 Tested up to 4,000 hours
or 1,500 cycles
 Tested up to 2000 hours
or 500 cycles
Weight, approx. 50 g
1) To prevent damage to the MDS at high temperature (depending on the expansion coefficients), an
M5 stainless steel screw must be used to attach it to the spacer (6GT2690-0AA00).
2) At higher temperatures (>+80 °C), the expansion coefficients of all materials must be observed
3) At temperatures of +140 °C and above, processing is not possible
Field data
Table C- 6 Field data for MDS D139
SLG D10/D10S
ANT D5
SLG D10/D10S
ANT D6
SLG D10/D10S
ANT D10
SLG D11/D11S
ANT D5
SLG D12/
SLG D12S
Operating distance (S
a
) 0 to 380 mm 0 to 480 mm 0 to 380 mm 0 to 240 mm 0 to 120 mm
Limit distance (S
g
) 450 mm 550 mm 450 mm 300 mm 150 mm
Transmission window (L) Ø 320 mm 520 mm 1000 mm Ø 300 mm 120 mm
Transmission window (W) 128 mm 420 mm 400 mm 120 mm 48 mm
Minimum distance from
MDS to MDS
≥ 1 m ≥ 1.5 m ≥ 2 m ≥ 1 m ≥ 0.5 m
ATEX
The MDS D139 mobile data memory is classed as a piece of simple, electrical equipment
and can be operated in the Category 2G protection zone.
