Metal-free area
KุPP
)OXVKPRXQWLQJRIWKH0'6LQPHWDOLVQRWSHUPLWWHG
0RXQWLQJRQPHWDO
'DWDVWRUDJH
XQLW
6SDFHU
0HWDO
PP
Figure C-6 Metal-free area for MDS D139
5HWDLQLQJEROW
6SDFHU
0'6'
Figure C-7 MDS D139: Mounting with a spacer
Note
If the minimum guide values (h) are not observed, a reduction of the field data results. It is
possible to mount the MDS with metal screws (M5). This has no tangible impact on the
range. It is recommended that a test is performed in critical applications.
When installing in the vicinity of metal, observe the instructions in the Section
Planning the
MOBY D system
.
