C.2 Discontinued SLG with ANT D5
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
313
Technical data
Table C- 8 Technical data for SLG D10 ANT D5
Inductive interface to the MDS
Transmission frequency 13.56 MHz
Transponders supported Transponders to ISO 15693 and I-Code1
Serial interface to the user RS 232 (RS 422 on request)
Transmission protocol Asynchronous 8 bit
Data transmission rate 9600 baud to 115.2 Kbaud
(adjustable)
Data backup CRC 16
Transmit power 4 W
Write/read distances SLG - MDS 480 mm typically (see field data)
1
Software functions Read, write, initialize MDS, access rights,
multitag
Programming Windows 9x, 2000, NT and XP with 32 bit
DLL available
Multitag Yes
Anti-collision speed approx. 20 labels/s simultaneously
identifiable
Power supply
'&9s
Current consumption
 Operation
 Inrush current, momentary
 0.9 A
 2.8 A/50 ms
Cable length, SLG - PC
 With RS 232  30 m (depending on data transfer rate)
Antenna cable length 3.60 m (included in scope of supply)
Digital inputs/outputs None
Dimensions (L x W x H) in mm
 For antenna
 For the electronics
 340 x 325 x 38
 320 x 145 x 100 without connector
Color
 Antenna
 SLG housing
 Black
 Anthracite
Material
 Antenna
 SLG housing
 Plastic ASA
 Aluminum
Connectors
 Antenna (plugs into SLG)
 V24 interface
 Power Supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
SLG fixing 4 x M6 screws
Antenna attachment 4 x M5 screws
