Previous versions
C.2 Discontinued SLG with ANT D5
MOBY D
328 System Manual, 01/2010, J31069-D0147-A6-7618
Connector
 Antenna (plugs into SLG)
 RS 422 interface
 Power supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
SLG fixing 4 x M6 screws
Antenna attachment 4 x M5 screws
Ambient temperature
 Operation
 Transport and storage
 -20 °C to +55 °C
 -25 °C to +70 °C
MTBF
 SLG D10S
 ANT D5
 7.5 x 10
4
hours
 3.0 x 10
5
hours
Degree of protection according to EN 60529
 SLG and antenna  IP65 (UL: for indoor use only)
Shock resistant according to EN 60721-3-7
Class 7M2
Total shock response spectrum Type II
30 g
Vibration according to EN 60721-3-7 Class 7M2 1 g (9 to 200 Hz)/
1.5 g (200 to 500 Hz)
Weight, approx.
 SLG
 Antenna
 3500 g
 1000 g
Approvals
 CE
 FCC
 IC
 Harmless to heart pacemakers
 UL 60950
1)
In order to ensure optimum field data even in the vicinity of metal, ANT D5 is calibrated at the
factory at a distance of 100 mm from metal.
CAUTION
The antenna cable is permanently preassembled. Any modifications made to the cable will
invalidate both the warranty and the CE approval.
Note
After detaching the ANT D5 antenna from the SLG and connecting it again (by screwing), an
init_run must always be performed.
