C.2 Discontinued SLG with ANT D5
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
335
Technical data
Table C- 17 Technical data for SLG D11S ANT D5
Inductive interface to the MDS
Transmission frequency 13.56 MHz
Transponders supported Transponders to ISO 15693 and I-Code1
Serial interface to the user RS 422
Transmission protocol Asynchronous 8 bit
Data transmission rate 19.2 Kbaud
Data backup CRC 16
Transmit power 1 W (reset parameter 04 hex)
Write/read distances SLG - MDS 380 mm typically (see field data)
1
Software functions Read, write and initialize MDS
Concatenated commands are not permitted.
The Repeat command is not implemented.
The largest possible useful data length in a command is 233
bytes.
Programming FC 45
Transmission protocol 3964R
Multitag no
Power supply
 Operation
 Permitted range

'&9

'&9s8/RQO\
'&99
Current consumption
 Operation
 Inrush current, momentary
 150 mA
 600 mA
Cable length SLG – SIMATIC S7
 With RS 422  300 m
Antenna cable length 3.60 m (included in scope of supply)
Digital inputs/outputs None
Dimensions (L x W x H) in mm
 For antenna
 For the electronics
 340 x 325 x 38
 160 x 80 x 40 without connector
Color
 Antenna
 SLG housing
 Black
 Anthracite
Material
 Antenna
 SLG housing
 Plastic ASA
 Plastic PA 12
Connectors
 Antenna (plugs into SLG)
 RS-422 interface
 Power Supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
