Planning the MOBY D system
4.7 Cable and connector assignment
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
93
Extension cable SLG D1xS ↔ ASM 456 /RF170C / RF180C
6GT2891-0F...
0FRQQHFWRU
PDOH
0FRQQHFWRU
VRFNHWIRU
FRQQHFWLQJFDEOH
$60
*7)+
$60VLGH &RXSOLQJVLGH







O









Figure 4-41 Extension cable SLG D1xS ↔ ASM 456
Antenna connecting cable SLG D10 / SLG D11 / SLG D10S / SLG D11S ↔ ANT Dx
6GT2691-0CH33
6GT2691-0CN10
Figure 4-42 ANT antenna connecting cable SLG D10 / SLG D11 / SLG D10S / SLG D11S ↔ ANT Dx
(3.3 m/10.5 m)
Antenna extension cable
6GT2691-0DH72
Figure 4-43 Antenna extension cable (7.2 m)
