Table 8-7 Error type of the channel-related diagnostics - manufacturer-specific
Error type Error text Meaning Remedy
10000
B
16
D
Parameter as‐
signment error
Parameter assignment error, e.g.:
● Module cannot use the parameter (unknown, invalid
combination, etc.)
● Module parameters not assigned
● User calibration does not correspond to the parameter
assignment
● Calibration error
Correction of the pa‐
rameter assignment
10001
B
17
D
No sensor or
load voltage
The following voltages can be missing:
● External supply voltage
● Voltage for operation of the module
Correction of the proc‐
ess wiring
10010
B
18
D
Fuse defective The user-replaceable fuse has blown Replace the fuse
10011
B
19
D
Communication
error
General communication error
For HART modules: Communication error with the HART field
device
Check the HART field
device, check the wir‐
ing
10100
B
20
D
Ground error Ground error (common mode error) e.g.:
● The permissible common mode voltage has been
exceeded in the case of non-isolated channels
● The M line is broken in the case of isolated channels
Correction of the proc‐
ess wiring
10101
B
21
D
Reference
channel fault
Error on the reference channel Replace the reference
channel module
10110
B
22
D
Hardware inter‐
rupt lost
At least one hardware interrupt could not be signaled
For HART modules: Additional status information of the
HART field device is available
Correction tuning of
program/
process/module
10111
B
23
D
Warning There could be a warning, if limit values like:
● Speed
● Load current
are exceeded
For HART modules: Maintenance request of the HART field
device
Correction tuning of
program/
process/module
11000
B
24
D
Tripping Tripping can be, for example:
● Circuit breaker has tripped due to short-circuit,
asymmetry, ground fault
● Thermistor has tripped
Eliminate the cause of
tripping and acknowl‐
edge, if necessary
11001
B
25
D
Safety-oriented
tripping
Trigger/cause for safety-related tripping is pending Eliminate the cause of
tripping
11010
B
26
D
External error External (process-side) error, e.g.:
● Sensor error
● Actuator error
● Sensor data is incorrect
For HART modules: Malfunction of the HART field device
Replace sensor/
actuator/ correct proc‐
ess wiring
Interrupt, error and system messages
8.3 S7 diagnostics
ET 200PA SMART
102 Operating Instructions, 06/2019, A5E34192013-AB
