10.4.3.1 Parameters of the AI 16 x 16 Bit
Parameter assignment
The parameters are assigned using the parameter assignment dialog of HW Config
Parameters of the AI 16 x 16 Bit
The table below provides an overview of the assignable parameters and their default settings
for the AI 16 x16 Bit.
The default settings apply when you have not assigned parameters in HW Config or you have
not changed any parameters.
Table 10-13 Parameters of analog input module AI 16 x 16
Parameter Value range Default setting Scope
Diagnostic interrupt enable Yes / No Yes Module
Diagnostics
Group diagnostics analog
Wire break check
Yes / No
Yes / No
Yes
Yes
Channel
Channel
Smoothing None
Weak
Medium
Strong
None Channel
Measurement type Disabled
4WMT
*
current
2WMT
*
current
4WMT
*
current Module
Measuring range Disabled
0 mA to 20 mA
**
4 mA to 20 mA
± 20 mA
**
4 mA to 20 mA Channel
Interference frequency sup‐
pression / integration time
60 Hz (16.6 ms)
50 Hz (20 ms);
10 Hz (100 ms);
50 Hz (20 ms) Channel
* 4WMT = 4-wire transducer; 2WMT = 2-wire transducer
** Can only be set for 4-wire transducer
Group diagnostics analog
The diagnostics parameter "Group diagnostics" enables the signaling of channel-specific
errors to be switched off, with the exception of parameter assignment errors.
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
184 Operating Instructions, 06/2019, A5E34192013-AB
