Group error display (SF LED)
The group error display (SF LED) of the ET 200PA SMART modules indicates the following:
● Operation of the ET 200PA SMART module centrally in an S7-300 system or an ET 200M
station. In this case, the SF LED flashes at 2 Hz. The ET200PA SMART module is not ready
for operation.
All the remaining modules can be operated without restriction.
● Error state of the respective module in the case of modules with diagnostic capability The
SF LED lights up as soon as diagnostic information of a module is detected. It goes out when
all causes of the diagnostic information (errors) are eliminated.
Internal module defects are indicated for modules with and without diagnostic capability. The
SF-LED lights up when a module defect has been detected.
10.2 Digital input modules
Overview of properties
The table below presents the ET 200PA SMART digital input modules based on their most
important properties.
Table 10-1 ET 200PA SMART digital input modules
Properties
Module
DI 16 x DC24V DI 32 x DC24V
6ES7650-8DK70-xAA0 6ES7650-8DK80-xAA0
Number of inputs 16
Isolated in groups of 16
32
Isolated in groups of 16
Rated input voltage 24 V DC 24 V DC
Suitable for... 2-/3-/4-wire proximity switches (BEROs)
Configurable
diagnostics
Yes No
Diagnostic interrupt Yes No
Adjustable input delays Yes, for entire module No
10.2.1 Digital input module DI 32 x DC 24 V
Article numbers
Standard module: 6ES7 650-8DK80-0AA0
Module with conformal coating: 6ES7 650-8DK80-1AA0
ET 200PA SMART I/O modules
10.2 Digital input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 125
