Interface module IM 650
9
Technical specifications
This section provides information on the following:
● The parameters of the IM 650 interface module
● The technical specifications of the IM 650 interface module
● Specifications regarding typical response times of an ET 200PA SMART station
● The dimension drawing of the IM 650 interface module
● The block diagram of the IM 650 interface module
ET 200 PA SMART modules
Information about the technical specifications and block diagrams of the ET 200PA SMART
modules as well as the corresponding dimension drawing can be found in the description of the
respective I/O module in section 10.
Reference Manual
The "S7-300 automation system, module specifications (
http://
support.automation.siemens.com/WW/view/en/8859629)" reference manual contains the
following for the modules from the S7-300 series of modules:
● The technical specifications
● The general technical specifications, such as specifications for noise immunity of the
modules as well as mechanical and climatic ambient conditions.
9.1 Parameters of the IM 650
Parameter assignment
You assign the parameters of the IM 650 or ET 200PA SMART via the parameter assignment
dialog of
HW Config .
Table 9-1 Parameters of the IM 650
Parameter Value range Default setting Scope
Start up at preset ≠ actual con‐
figuration?
Yes / No Yes ET 200PA SMART
"Module replacement in run‐
time"?
Yes / No Yes ET 200PA SMART
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 117
