Technical specifications of the DI 16 x DC 24 V
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight Approx. 200 g
Module-specific data
Number of inputs 16
Cable length
● Unshielded
● Shielded
Max. 600 m
Max. 1000 m
Voltages, currents, potentials
Rated supply voltage of electronics and sensors L+ 24 V DC
● Reverse polarity protection
Yes
Number of simultaneously controllable inputs
● Horizontal mounting position
Up to 60 °C
16
● Vertical mounting position
Up to 40 °C
16
Electrical isolation
● Between channels plus sensor circuits (L+) and backplane bus
● Between channels
– in groups of
Yes
16
Isolation, designed for basic isolation
● Between different circuits
75 V DC / 60 V AC
Isolation tested with 500 V AC or 707 V DC, type test
Current consumption
● From backplane bus
Max. 130 mA
● From load voltage L+ (without sensor supply V
S
)
Max. 90 mA
Power loss of the module Typ. 4 W
Status, interrupts, diagnostics
Status display Green LED per channel
Sensor supply status Green LED per sensor supply output
Group error display (SF LED) Yes
Diagnostic interrupts Configurable
Diagnostic functions Configurable
Sensor supply outputs
Number of outputs 2
Output voltage
● On load
Min. L+ (- 2.5 V)
Output current
● Rated value
● Permitted range
120 mA
0 to 150 mA
ET 200PA SMART I/O modules
10.2 Digital input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 133
