Siemens SIMATIC PCS 7 Operating Instructions

Technical specifications
Cable length
● Unshielded
● Shielded
Max. 600 m
Max. 1000 m
Voltages, currents, potentials
Rated load voltage L+ 24 V DC
Reverse polarity protection No
Total current of outputs (per group)
● Horizontal mounting position up to 60 °C
Max. 2 A
● Vertical mounting position up to 40 °C
Max. 2 A
Electrical isolation
● Between channels and backplane bus
Yes
● Between channels
in groups of
Yes
4
Isolation, designed for basic isolation
● Between different circuits
75 V DC / 60 V AC
Isolation tested with 500 V AC or 707 V DC, type test
Current consumption
● From backplane bus
● From load voltage L+ (no load)
Max. 100 mA
Max. 100 mA
Power loss of the module Typ. 6 W
Status, interrupts, diagnostics
Status display Green LED per channel
Group error display (SF LED) Yes
Diagnostic interrupt Configurable
Diagnostic functions Configurable
Actuator selection data
Output voltage
● When signal "1" is present
Min. L+ (-1.3 V)
● When signal "0" is present
0.7 mA * RL (RL = load resistance value)
Max. 31 V when RL = infinite
Output current
● When signal "1" is present
Rated value
Permitted range
0.5 A
5 mA to 0.6 A
● When signal "0" is present (residual current)
Max. 0.7 mA
Output delay (with resistive load)
● At "0" to "1" transition
Max. 2.7 ms (including module cycle time)
● At "1" to "0" transition
Max. 2.7 ms (including module cycle time)
Load resistance range 48 Ω to 4 kΩ
Lamp load Max. 5 W
Connection of 2 outputs in parallel
● For redundant control of a load
Supported
ET 200PA SMART I/O modules
10.3 Digital output modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 145
