Properties Module
AI8x13-bit AI8x16Bit AI16x16Bit AI8xTC/4xRTD
6ES7650-8AE60-xAA0 6ES7 650-8AK60-xAA0 6ES7 650-8AK70-xAA0 6ES7 650-8AR60-xAA0
Measurement
type
Can be set for each
channel group:
● Voltage
● Current
● Resistance
● Thermal resistance
Global changeover possi‐
ble with a jumper be‐
tween pins 10 & 11:
● 2-wire transducer
current
● 4-wire transducer
current
Global changeover possi‐
ble with a jumper between
pins 10 & 11:
● 2-wire transducer
current
● 4-wire transducer
current
Can be set for each
channel group:
● Voltage
● Resistance
● Thermal resistance
● Thermocouple
Measuring
range selec‐
tion
Any, per channel Any, per channel Any, per channel Any, per channel
Configurable
diagnostics
Yes Yes Yes Yes
Diagnostic in‐
terrupt
Can be set Can be set Can be set Can be set
Electrical iso‐
lation
From:
● Backplane bus
interface
In relation to:
● Backplane bus
interface
● Load voltage (not for
2-wire transducer)
From:
● Backplane bus
interface
● Load voltage (not for 2-
wire transducer)
From:
● Backplane bus
interface
Isolation, de‐
signed for ba‐
sic isolation
75 V DC
60 V AC
75 V DC
60 V AC
75 V DC
60 V AC
75 V DC
60 V AC
Basics
A variety of transducers can be connected to the analog input modules. These measuring
transducers are, for example:
● Voltage sensors
● Current sensors
● Resistors / thermistors
● Thermocouples
You can find the following information in the manual SIMATIC S7-300 Automation System,
Module Data (
http://support.automation.siemens.com/WW/view/en/8859629
/) :
● Basics regarding the basic procedure for connecting the various transducers to the analog
inputs
● Basics of analog value processing
● Information on the analog value formats used in each case
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 151
