Siemens SIMATIC PCS 7 Operating Instructions

Technical specifications
● Resistance thermometer/silicon temperature sensors
Pt 100
Ni 100
Standard
± 1 K
Pt 100
Ni 100
Klima
± 0.8 K
Ni 1000
LG-Ni 1000
Standard
± 0.8 K
Ni 1000
LG-Ni
1000 Klima
± 0.8 K
KTY83/110
KTY84/130
± 2 K
± 2.7 K
Temperature error (relative to input range) ± 0.006 %/K / 0.006 K/K
Linearity error (relative to input range) ± 0.1 % / 0.1 K
Repeat accuracy (in transient state at 25 °C, relative to input
range)
± 0.1 % / ± 0.1 K
Status, interrupts, diagnostics
Interrupts none
Diagnostic functions none
Sensor selection data
Input ranges (rated values) / input impedance
● Voltage
± 50 mV
± 500 mV
± 1 V
± 5 V
± 10 V
1 V to 5 V
0 V to 10 V
100 kΩ
● Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
100 Ω
● Resistor/PTC
0 kΩ to 6 kΩ
0 Ω to 600 Ω
PTC
100 MΩ
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 159
