I&M data Access Default setting Explanation
ORDER_ID read (20 bytes) depending on the
module
The article number of the module is stored here.
SERIAL_NUMBER read (16 bytes) depending on the
module
The serial number of the module is stored here.
This enables unique identification of the module.
HARDWARE_REVISION read (2 bytes) depending on the
module
The version of the module is stored here.
Incremented when the hardware or firmware of the
module changes.
SOFTWARE_REVISION read (4 bytes) Firmware version Provides information about the firmware version of
the module.
If the firmware version number is incremented, then
the version of the module (HARDWARE_REVI‐
SION) is also incremented.
REVISION_COUNTER read (2 bytes) 0000 hex Reserved
PROFILE_ID read (2 bytes) F600 hex Means "Generic Device"
PROFILE_SPECIF‐
IC_TYPE
read (2 bytes) 0005 hex On interface modules
IM_VERSION read (2 bytes) 0101 hex Provides information about the version of the I&M
data. (0101 hex = Version 1.1)
IM_SUPPORTED read (2 bytes) 000E hex Shows information about the I&M data. (Index 2 to
4)
Maintenance data 1: Index 2 (data record 232)
TAG_FUNCTION read / write
(32 bytes)
– Enter a system-wide unique identification for the
module here.
TAG_LOCATION read / write
(22 bytes)
– Enter the installation location of the module here.
Maintenance data 2: Index 3 (data record 233)
INSTALLATION_DATE read / write
(16 bytes)
– Enter the installation date and, if necessary, the as‐
sociated time for the module.
RESERVED read / write
(38 bytes)
– Reserved
Maintenance data 3: Index 4 (data record 234)
DESCRIPTOR read / write
(54 bytes)
– Enter a comment regarding the module here.
Functions
7.8 Identification and maintenance data (I&M data)
ET 200PA SMART
86 Operating Instructions, 06/2019, A5E34192013-AB
