System overview
5.4 Communication
S7-1500R/H redundant system
122 System Manual, 01/2024, A5E41814787-AF
5.4.3 HMI devices
HMI devices are used for machine-level process visualization and control. You use the same
HMI devices for the S7-1500R/H redundant system as for the standard S7-1500 system.
Using HMI communication, one or more HMI devices exchange data with the CPUs . Examples
of HMI devices are HMI Basic/Comfort/Mobile Panel.
The connection of the HMI device to the redundant system depends on the specific
application. In STEP 7, you can configure the following communication options:
• The HMI device communicates with the redundant system via a system IP address.
• The HMI device communicates with the respective R/H-CPUs (for example for diagnostic
purposes) via device IP addresses.
More information
You can find more information on using HMI devices in the Using HMI devices (Page 228)
section and in the Communication Function Manual
(https://support.industry.siemens.com/cs/ww/en/view/59192925).
You can find an overview of all available HMI devices in the Industry Mall
(https://mall.industry.siemens.com/mall/en/WW/Catalog/Products/9109999?tree=CatalogTree)
.
5.4.4 Communications processor CP1543-1
The communications processor CP 1543-1 provides a redundant connection of the
S7-1500 R/H CPUs to Industrial Ethernet.
You can use up to 2 (R-System)/6 (H-System) CP 1543-1 communications processors per
R/H-CPU.
The table below gives an overview of the most important properties and communication
services of the CP 1543-1:
Equipment Manual
Functionality and protocols
TCP/IP, ISO, UDP, TCP, S7 communication, IP Broad-
cast/Multicast, Security, Secure Open User Communication,
SMTPS, diagnostics SNMPV1/V3, FTP client/server, email,
